m ATTENTION!
The device and the packaging material are not
children‘s toys! Do not let children play with
plastic bags, lms or small parts! There is a dan-
ger of choking or suocating!
9. Assembly
Assembling the lathe (Fig. 2)
1. Slide the tool support (2) onto the rail with motor
unit (3a).
2. Slide the tailstock (5) to the tool support (2) on
the rail with the motor unit (3a). Check that the
tailstock (5) and tool support (2) are correctly in-
serted by pulling them upwards.
3. Connect the rail with the motor unit (3a) and the
rail (3b) without the motor unit together.
4. Screw the two rails together with the three screws
withspring washer and standard washer (17) us-
ing the Allen key (12).
Note:
If it is dicult to move the tool support (2) or the
tailstock (5), adjust the nut on the underside with
a spanner or ratchet (19 mm).
Setting up the lathe (Fig. 1)
1. Place the lathe on a rm surface.
2. Screw the lathe to the surface. Use the two holes
in each of the three feet (7) for this.
3. You can use the hexagonal bolts (18) supplied
with the lathe for this.
4. Place the standard washer and spring washer on
the hexagonal bolt (18). See g. 1.
5. Screw the lathe to the surface with the help of the
hexagonal bolt, standard washer, spring washer
and nut (18).
Fitting/replacing the workpiece mount (Fig. 3)
m ATTENTION!
Switch the device o and pull out the mains plug.
Fitting the 4-prong centre tip
1. Loosen the face plate (13) if necessary. To do this,
hold the drive shaft (19) rmly in place with the
open-ended spanner (16) and unscrew the face
plate (13) from the drive shaft (19).
2. Hold the drive shaft (19) rmly in place with the
open-ended spanner (16).
3. Tighten the 4-prong centre tip (1) onto the drive
shaft using the second open-ended spanner (16).
For turning bowls or pots, for example, the face plate
(13) must be used instead of the 4-prong centre tip
(1).
7. Technical data
Dimensions L x W x H 1375 x 325x 415 mm
Speed 890/1260/1760/2600 min
-1
Max. workpiece size 1000 mm
Max. workpiece
diameter
350 mm
Spindle head thread M18 x 2,5
Weight 20 kg
Engine 230-240 V /50 Hz
Rated input 400 W S2 15 min
Subject to technical changes
* Operating mode S2 – short-term operation
Operation at a constant load for 15 minutes or less,
followed by a time out of operation and a pause of
sucient duration to allow the machine to cool to
within 2 K of the ambient temperature.
The noise and vibration levels have been determined
in accordance with EN 61029.
Sound pressure level L
pA
71 dB(A)
Uncertainty K
pA
3 dB
Sound power level L
WA
84 dB(A)
Uncertainty K
WA
3 dB
Wear hearing protection.
Excessive noise can result in a loss of hearing. Total
vibration emission values (vector sum of three direc-
tions) determined per EN 61029.
8. Unpacking
• Open the packaging and carefully remove the de-
vice.
• Remove the packaging material, as well as the
packaging and transport safety devices (if present).
• Check whether the scope of delivery is complete.
• Check the device and accessory parts for transport
damage. In the event of complaints the carrier must
be informed immediately. Later claims will not be
recognised.
• If possible, keep the packaging until the expiry of
the warranty period.
• Familiarise yourself with the product by means of
the operating instructions before using for the rst
time.
• With accessories as well as wearing parts and re-
placement parts use only original parts. Replace-
ment parts can be obtained from your dealer.
• When ordering please provide our article number
as well as type and year of manufacture for your
equipment.
