15. Disposal and recycling
Disposing of transport packaging
The packaging protects the machine from damage during transport. The packaging material is usually chosen for factors of
environmental friendliness and disposal. It can therefore be recycled. Returning the packaging to the material life cycle saves
raw material and reduces waste.
Packaging parts (e.g. plastic sheets, Styropor®) can be dangerous for children. Risk of choking! Store packaging parts beyond
the reach of children and dispose of them as soon as possible.
Old devices must not be disposed of with household waste!
This symbol indicates that this product must not be disposed of together with domestic waste in compliance with the
Directive (2012/19/EU) pertaining to waste electrical and electronic equipment (WEEE). This product must be disposed
of at a designated collection point. This can occur, for example, by handing it in at an authorised collecting point for
the recycling of waste electrical and electronic equipment. Improper handling of waste equipment may have negative
consequences for the environment and human health due to potentially hazardous substances that are often contained in
electrical and electronic equipment. By properly disposing of this product, you are also contributing to the effective use of
natural resources. You can obtain information on collection points for waste equipment from your municipal administration,
public waste disposal authority, an authorised body for the disposal of waste electrical and electronic equipment or your waste
disposal company.
16. Troubleshooting
Problem Possible Cause Help
Saw blade gets loose
after turning off the
motor
Fastening nut tightened insufciently Tighten fastening nut, M20 left-handed thread
Motor does not start a) Fastening nut tightened insufciently
b) Extension cable defect
c) Connections on the motor or switch defect
a) Check the mains fuse.
b) See “Electrical Connection” in the operating
manual
c) Have it checked by an electrician
No motor output turns
off automatically
Overload by dull saw blade, thermoprotection
is triggered
Insert a sharpened saw blade; motor can be turned
on again after the cooling period
Burns on the cutting
surface
c) with longitudinal cuts
d) with cross cuts
a) Fastening nut tightened insufciently
b) Wrong saw blade
c) Longitudinal stop not parallel
d) Slide carriage not parallel
a) Insert a sharpened saw blade
b) Insert saw blade with 20 or 28 teeth for
longitudinal cuts
c) Exchange the longitudinal stop
Align the slide carriage with the saw blade
30 І 60

Scheppach HS105 Specifications

General

Product color	Blue, White
Built-in light	No
Country of origin	Germany
Suitable for materials	Wood
Saw blade included	Yes
Input power	2000 W
Power source	AC
AC input voltage	230 V
AC input frequency	50 Hz
Blade diameter	255 mm
Number of teeth	60
Idle speed (max)	7000 RPM
Bevel capacity (max)	45 °
Cutting depth (45º)	50 mm
Cutting depth (90º)	80 mm

Weight and Dimensions

Depth	760 mm
Width	690 mm
Height	380 mm
Weight	30500 g
