Scheppach HS120 Translation From Original Manual

21
• As the user, you are required to ensure, in consulta-
tion with your electric power company if necessary, that
the connection point at which you wish to operate the
product meets one of the two requirements, a) or b),
named above.
Maintenance
Warning: Turn off the machine and disconnect from the
power supply before conducting maintenance work or set-
tings.
Store the manual close to the machine.
Keep the machine clean.
Wear goggles when cleaning the machine.
Caution: Do not clean synthetic components of the bench
using aggressive cleaning agents. We recommend a mild
dish washing liquid. The machine must not get into con-
tact with water.
• Check the saw blade regularly. Use only well-sharp-
ened, crack-free and not distorted saws. Use only tools
that comply with the European standard EN 847-1.
• Exchange immediately table lining that run out.
• Always keep table surface nonresinous.
• Clean regularly the inner section of the machine, like
tooth segement and pinion of the oscillating device, of
wood and chip rests.
• Remove possible sawdust blockages at the discharge.
Have your electric tool repaired by a qualified electrician.
This electric tool conforms to the applicable safety
regulations. Repairs may only be performed by an electri-
cian using original spare parts. Otherwise accidents can
occur.
Troubleshooting table
Warning: In the interests of operational safety, always switch off the saw and remove the mains plug before carrying out maintenance
work.
Problem Possible Cause Help
Saw blade gets loose after
turning off the motor
Fastening nut tightened insufficiently Tighten fastening nut, M20 left-handed thread
Motor does not start a) Fastening nut tightened insufficiently
b) Extension cable defect
c) Connections on the motor or switch defect
a) Check the mains fuse.
b) See “Electrical Connection” in the operating
manual
c) Have it checked by an electrician
No motor output turns off
automatically
Overload by dull saw blade, thermoprotection is
triggered
Insert a sharpened saw blade; motor can be
turned on again after the cooling period
Burns on the cutting
surface
c) with longitudinal cuts
d) with cross cuts
a) Fastening nut tightened insufficiently
b) Wrong saw blade
c) Longitudinal stop not parallel
d) Slide carriage not parallel
a) Insert a sharpened saw blade
b) Insert saw blade with 20 or 28 teeth for
longitudinal cuts
c) Exchange the longitudinal stop
Align the slide carriage with the saw blade

Scheppach HS120 Specifications

General

Idle speed	- RPM
Cutting height @ 45°	49 mm
Cutting height @ 90°	83 mm
Product color	Blue, Stainless steel
Placement supported	Freestanding
Input power	2000 W
AC input voltage	230 V
AC input frequency	50 Hz
Saw blade type	Single
Number of teeth	24
Saw blade included	Yes
Number of saw blades	1

Weight and Dimensions

Depth	1690 mm
Width	615 mm
Height	1055 mm
Weight	48600 g
Table depth	800 mm
Table width	550 mm
Blade diameter	315 mm
Base plate width	400 mm
Blade diameter (min)	20 mm
