7
of narrow workpieces (less than 120 mm). The
push-stick must be used to prevent you from hav-
ing to work with your hands near the sawblade.
Stop the machine to repair a failure or remove pieces
of wood which have become jammed. Disconnect the
mains plug.
• Use the push stick or the feed lever for sliding the
wood, to guide it safely past the saw blade.
• Switch the machine off and pull power supply plug
when rectifying any malfunctions.
• The table insert must be renewed when the saw slot is
worn down. Pull power supply plug.
• Before the machine is put into operation it must be
connected to a dust extractor with a flexible, non-flam-
mable suction hose. The suction should switch on auto-
matically when the machine is switched on.
• When leaving the work place, switch the motor off. Pull
the power supply plug.
• Cut off the external power supply of the machine or
plant even if only minor changes of place are envisaged.
Properly reconnect the machine to the supply mains
before recommissioning.
• Connection and repair work on the electrical installation
may be carried out by a qualified electrician only.
• All protection and safety devices must be replaced after
completing repair and maintenance procedures.
Accessories
Only purchase accessories from your authorised special-
ised dealer.
m Use only as authorized
The machine corresponds to the valid EC guideline.
CE tested machines meet all valid EC machine guidelines as
well as all relevent guidelines for each machine.
• The machine has been built in accordance with state-
of-the-art standards and the recognized safety rules.
Nevertheless, its use may constitute a risk to life and
limb of the user or of third parties, or cause damage to
the machine and to other material property.
• The circular saw bench is constructed exclusively for
the sawing of wood. The required saw blade should be
inserted according to the cut type and the wood type
(solid wood, chip board or plywood).
• The machine must only be used in technically perfect
condition in accordance with its designated use and the
instructions set out in the operating manual, and only
by safety-conscious persons who are fully aware of the
risks involved in operating the machine. Any functional
disorders, especially those affecting the safety of the
machine, should therefore be rectified immediately.
• When used in enclosed rooms, the machine must
be connected to a vacuum exhaust unit. Use the vacu-
um exhaust unit or ha 2600 to remove matchwood or
saw dust. The vacuum support flow rate must be 20
m/s. Subatmospheric pressure 1200 Pa.
• The automatic switching unit is available as a special
accessory. The vacuum exhaust unit auto matically
switches on after a 2-3 second delay after the machine
tool is turned on. This avoids overloading the circuit
fuse. After turning off the machine tool, the vacuum
exhaust unit remains on for an additional 3-4 seconds
and is then automatically switched off. Remaining dust
is thereby removed by vacuum exhaust, as required by
German regulations governing hazardous materials.
This results in savings in electricity consumption and
reduces noise levels, as the vacuum exhaust unit is on
only during machine tool operation.
• For work in commercial spaces, the dust remover woova
7 must be used. Do not remove or shut off vacuum ex-
haust systems or dust removers while machine tools are
operating.
• Any other use exceeds authorization. The manufacturer
is not responsible for any damages resulting from un-
authorized use; risk is the sole responsibility of the op-
erator.
• The safety, work and maintenance instructions of the
manufacturer as well as the technical data given in the
calibrations and dimensions must be adhered to.
• Relevant accident prevention regulations and other,
generally recognized safety-technical rules must also
be adhered to.
• The Table Circular Saw may only be used, maintained,
and operated by persons familiar with and instructed
in its operation and procedures. Arbitrary alterations to
the machine release the manu facturer from all respon-
sibility for any resulting damages.
• The Table Circular Saw may only be used with original
accessories and saw blades from the manufacturer.
m
Remaining hazards
The machine has been built using modern technology in ac-
cordance with recognized safety rules. Some remaining haz-
ards, however, may still exist.
• The rotating saw blade can cause injuries to fingers and
hands if the work piece is incorrectly fed.
• Thrown work pieces can lead to injury if the work piece
is not properly secured or fed, such as working without
a limit stop.
• Noise can be a health hazard. The permitted noise level
is exceeded when working. Be sure to wear personal
protective gear such as ear protection.
• Defective saw blades can cause injuries. Regularly in-
spect the structural integrity of saw blades.
• The use of incorrect or damaged mains cables can lead
to injuries caused by electricity.
• The operating instructions supplied with the special
accessories must be observed and carefully read when
Scheppach special accessories are used.
• Even when all safety measures are taken, some remain-
ing hazards which are not yet evident may still be pre-
sent.
• Remaining hazards can be minimized by following the
instructions in “Safety Precautions“, “Proper Use“ and
in the entire operating manual.
