2. Procedures
2.1. Sheath Placement (Wired Sensors)
We have supplied specific use instructions for each holder in this section, but the first steps
are common to all holders and sheaths used with wired Sensors, as shown below.
Table 1. Overview of Sheath and Holder Placement with Wired Sensors
Step Instruction Illustration
1.
Select the appropriate size Sheath
for the Wired Sensor
2. Slide the Sensor into the Sheath
3.
Position the Holder on the Sheath
(Actual position will vary with
holder and area to be X-rayed.
Continue with the following
paragraphs for specific placement
information)
