Schiit FREYA S - Connections; Balanced Inputs; Single-Ended Inputs; Balanced Output

1 2 3 4 5
INPUT 1 INPUT 2 BAL OUT SE OUTSIN 3 IN 4 IN 5
ASSEMBLED IN USA
3 Balanced Output
Connect to external power ampliers or
powered speakers that accept XLR
connections, using good XLR cables.
4 Single-Ended Output
Connect to external power ampliers or
powered speakers that accept RCA con-
nections, using high-quality RCA cables,
especially for longer runs.
1 Balanced Inputs
Freya S offers two sets of balanced inputs.
Connect to your balanced sources using XLR
cables. You can select your source with the
front panel controls.
2 Single-Ended Inputs
Freya S offers three sets of single-ended
inputs. Connect your single-ended sources
here using good RCA cables. Note that Freya
will not convert single-ended to balanced
sources when you are in passive mode.
5 Power Switch
Up for on, down for off. No tricks here.
6 Power Inlet
Plug the end of the supplied IEC cord in
here. You can also use fancy audiophile
types, but they won’t really do anything—
what about the thousands of feet of crap
copper cables in your walls, huh?
CONNECTIONS
1 2 3 4 51 2 2 6
