Schiller AT-2plus - Manual Mode

Page 1.10
SCHILLER AT-2plus 6-Channel ECG Unit
SERVICE HANDBOOK Issue 1 June 1998
Chapter 1
Operating Elements
Manual Mode
Manual mode provides a direct printout of the real-time ECG with full control of parameter
selection.
To start the manual recording of a real-time ECG, press the MANUAL Printout key
To stop the manual recording (printout) press the STOP key
The printout provides you with the following:
 Six (selected) leads with lead identification.
 On the lower edge, the chart speed, user identification and filter settings (if on).
 At the top, the heart rate as current average of 4 beats, trace sensitivity, and the time and
date
The following can be freely chosen during or before the recording:
Lead Group by means of the LEAD FORWARD and LEAD BACKWARD
key
! "
The following lead groups are selectable:
 I, II, III aVR, aVL, aVF
(Cabrera: aVL, I, -aVR / II, aVF, III)
 V1, V2, V3 / V4, V5, V6
 II, aVF, III / V2, V4, V5
 V4, V5, V6 / V7, V8, V9
Note: The LCD only displays three leads at one time. When the lead forward or lead backward
key is pressed, the following /preceding three lead group is displayed
