Schlage M450 - Lock Magnet Securing; Wiring Connections; Standard Model Wiring

7
6 Install lock
6a Install magnet and secure with screws
Actual Size
7 Connect wiring to board (standard model)
7a Review wiring connections
TB1
Printed Circuit Board
DC Power
DC (+)
DC (-)
From Magnet
7b Connect wires to board
From Door Frame
DC Power Wires
From Magnet
7c Install cover.
