Rehanding Instructions
1 Remove housing screws.
2 Slide out top endcap.
3 Slide out bottom endcap and magnet.
L Do not pull wires completely through.
4 Flip the housing 180°.
5 Remove the bolts from both endcaps, flip 180° and
reinsert into bottom of endcaps.
NOTE: Be careful to not pinch any cables in the bottom endcap with the
screw!
6 Slide the magnet and bottom endcap into the
housing.
7 Slide in the top endcap.
8 Insert and tighten endcap screws.
A
B
