14. Appendix
Reference Manual |Edition 4.0 (10-2013) |
EcoCut 3300
79|108
12» The upgrade process is started automatically.
The progress is shown in the window (8).
13» If the info box „Upgrade successful comple-
ted!“ pops up, the upgrade process is finished.
14» [OK] (9).
15»
The EcoCut 3300 starts the machine software
automatically.
14.2
CONNECTOR HS / PF
14.2.1
For use with a PreFeeder
With Schleuniger PreFeeders the appropriate connection cable is delivered with the Prefeeder. As per the
following diagram, the D-sub-connector can be self-wired by a qualified technician.
