8. Disassembly and disposal
8.1 Disassembly
The safety switchgear must be disassembled in a de-energised
condition only.
8.2 Disposal
The safety switchgear must be disposed of in an appropriate manner in
accordance with the national prescriptions and legislations.
7. Set-up and maintenance
7.1 Functional testing
The safety function of the safety components must be tested.
The following conditions must be previously checked and met:
1. Fitting of the sensor and the actuator.
2. Fitting and integrity of the power cable.
3. The system is free of dirt and soiling (in particular metal chips).
7.2 Maintenance
In the case of correct installation and adequate use, the safety sensor
features maintenance-free functionality.
A regular visual inspection and functional test, including the following
steps, is recommended:
1. Check the fitting and integrity of the safety sensor, the actuator and
the cable.
2. Remove possible metal chips.
Adequate measures must be taken to ensure protection
against tampering either to prevent tampering of the safety
guard, for instance by means of replacement actuators.
Damaged or defective components must be replaced.
9. Appendix
9.1 Wiring configuration and connector accessories
Function safety switchgear Pin configuration of
the connector
Colour codes of the Schmersal
connectors
Poss. colour codes
of other customary
connectors
8-pin version ST 5-pin ST5
with conventional
diagnostic output
with serial
diagnostic function
5
8
4
3
2
1
7
6
3
2
5
1
4
IP67 / IP69
(PUR)
IP69
(PVC)
IP67 / IP69
(PUR)
to
IEC 60947-5-2: 2007
A1 U
e
1 1 WH BN BN BN
X1 Safety input 1 2 BN WH WH
A2 GND 3 3 GN BU BU BU
Y1 Safety output 1 4 4 YE BK BK BK
OUT Diagnostic output SD output 5 5 GY GY GY GY
X2 Safety input 2 6 PK VT PK
Y2 Safety output 2 7 2 BU RD WH VT
IN without function SD input 8 RD PK OR
Connecting cables (PUR) with coupling (female),
IP67 / IP69, M12, 8-pin, 8 x 0.23 mm², to DIN 47100
Connecting cables (PVC) with coupling (female),
IP69, M12, 8-pin, 8 x 0.21 mm²
Cable length Part number Cable length Part number
2.5 m
5.0 m
10.0 m
103011415
103007358
103007359
5.0 m
5.0 m, angled
10.0 m
15.0 m
101210560
101210561
103001389
103014823
Connecting cables (PUR) with coupling (female),
IP67 / IP69, M12, 5-pin, 8 x 0.23 mm², to IEC 60947-5-2
Cable length Part number
5.0 m
10.0 m
15.0 m
103010816
103010818
103010820
