3
SLC440
Operating instructions
Safety light curtain
EN
Test rod PLS
The test rod is used for testing the protection field.
MSD4 Vibration damper
Kit consists of: 8 vibration dampers 15 x 20 mm, 8 M5 cylinder head
screws with hexagon socket, 8 spring washers. Mounting using MS-1100.
The MSD4 vibration damper kit is recommend to be used for damping
vibrations and oscillations on the SLC440. For applications with higher
mechanical stresses, e.g. presses, punching machines, we recommend
the MSD4 kit. In this way, the availability of the SLC440 is increased.
Integrated status indication
The SLC440 series is also available with integrated status indication
(red/yellow/green) installed onto the receiver. (See ordering code)
2.5 Technical data
Standards: EN 61496-1; EN 61496-2;
EN ISO 13849; EN 62061
Material of the enclosure: Aluminium
Protection field heights:
- Resolution 14 mm
170 mm - 1930 mm
- Resolution 30 mm 170 mm - 1930 mm
Detection ability for test bodies: 14 mm and 30 mm
Range of the protection field:
- Resolution 14 mm
0.3 … 7.0 m
- Resolution 30 mm 0.3 … 10.0 m
Response time:
- beam coding (normal)
1 - 48 beams = 10 ms
49 - 144 beams = 20 ms
145 - 192 beams = 28 ms
- beam coding A 1 - 48 beams = 15 ms
49 - 144 beams = 27 ms
145 - 192 beams = 40 ms
Rated operating voltage: 24 VDC ±10% (PELV) supply unit
I
max.
2.0 A, to EN 60204
Rated operating current: 250 mA max. + 2 x 0.25 A each OSSD
Wavelength of the infrared radiation: 880 nm
Transmitter, infrared emitted radiation
- to DIN EN 12198-1: Category 0
- to DIN EN 62471: free group
Safety outputs
OSSD1, OSSD2:
2 x short-circuit proof PNP
semi-conductor outputs
Test impulse cycle OSSD: 750 ms
Test impulse length: 100 µs
Switching voltage HIGH¹: 15 … 26.4 V
Switching voltage LOW¹: 0 … 2 V
Switching current each OSSD: 0 … 250 mA
Leakage current²: 1 mA
Load capacity: 0 … 2.2 µF
Load inductivity³: 0 … 2H
Admissible conduction resistance between OSSD and load:
Admissible conduction resistance of the supply cable:
Contactor control (EDM)
Input voltage HIGH (inactive): 11 … 30 V
Input voltage LOW (active): 0 … 2.0 V
Input current HIGH: 3 … 10 mA
Input current LOW: 0 … 2 mA
Input release restart interlock/restart interlock 2
Input voltage HIGH (active): 11 … 30 V
Input voltage LOW (inactive): 0 … 2.0 V
Input current HIGH: 3 … 10 mA
Input current LOW: 0 … 3 mA
Functions: automatic mode, restart interlock,
double reset, contactor control,
beam blanking fixed and floating,
beam coding A
Signal times
Contactor control: max. 500 ms
Restart interlock (manual reset): 50 ms … 1.5 s, signal
transmission in case of trailing edge
LED indications transmitter: transmitting, status
LED indications receiver: OSSD ON, OSSD OFF, restart, signal
reception, blanking, information
Connection: M12 connector plug with metal thread, receiver 8-pole,
transmitter 4-pole
Ambient temperature:
Storage temperature:
Interface: Diagnostics and function setting
Protection class: IP67 (IEC 60529)
Resistance to vibration: 10 … 55 Hz to IEC 60068-2-6
Resistance to shock: 10 g, 16 ms, to IEC 60028-2-29
Year of construction: as of 2014 version 2.0
¹) To IEC 61131-2
²) In case of failure, the leakage current at the most flows to the OSSD
cable. The downstream control element must recognise this state as
LOW. A safety PLC must detect this state.
³) The load inductivity generates an induced voltage during the switch-off,
which compromises the downstream components (spark quenching
element).
2.6 Response time (reaction time)
The response time depends on the hight of the protection field, the
resolution, the number of light beams and the beam coding A.
Resolution 14 mm
Protection
field height
[mm]
Beams
(Lines)
[Number]
Response
time
[ms]
Response time
with Beam coding
A [ms]
Weight
[kg]
170 16 10 15 0.4
250 24 10 15 0.5
330 32 10 15 0.6
410 40 10 15 0.8
490 48 10 15 0.9
570 56 20 27 1.0
650 64 20 27 1.1
730 72 20 27 1.2
810 80 20 27 1.4
890 88 20 27 1.5
970 96 20 27 1.6
1050 104 20 27 1.7
1130 112 20 27 1.8
1210 120 20 27 2.0
1290 128 20 27 2.1
1370 136 20 27 2.2
1450 144 20 27 2.3
1530 152 28 40 2.4
1610 160 28 40 2.6
1690 168 28 40 2.7
1770 176 28 40 2.8
1850 184 28 40 2.9
1930 192 28 40 3.0
