ACCUMULATING WEIGHTS
Press after each weighing to add that weight to the accumulated total (‘ADD 1’, ‘ADD 2’,
‘ADD 3’ etc will be displayed) The ‘ADD key must be pressed at every weighing to ensure the weight
is added to the total.
TO DISPLAY THE CURRENT ACCUMULATED TOTAL
Press to recall the total weight so far, this will not add any weight to the current total or
clear the weight
TO CLEAR THE TOTAL
Press to clear the accumulated weights and reset to ‘0’
Please Note: To ensure the Weigh System will not allow the same lifted weight to be added
twice, the weigh system must “see” zero or no load on the forks before allowing another
weight reading to be added.
IMPORTANT NOTE:
An error message ERR 4 may appear on the Display on Power Up.
ERR 4 signifies that the input signal from the Transducer is different to the calibrated signal value for
ZERO.
This could be because the forks are on the ground or that there is a load on the forks.
Please continue to use the Weigh system as described
Contact your local distributor if you experience any further difficulties.
3.2 MACHINE CONDITION:
To achieve an accuracy of approximately + /– 1 % of the capacity of the machine, the
machine should be in the best possible mechanical and hydraulic condition.
NOTE:
Due to the potential safety hazards to personnel, it is strongly recommended that
only qualified mechanics work on the machine.
3.3 INSTALLATION KIT:
To facilitate installation, a kit containing all necessary hardware has been included in the
monitor-packing carton. Typically this includes the following components.
• FWS 114
Display
• Sensor assembly
• Display Monitor mounting bracket
• Operation stickers
• Hydraulic hose and fitting
• Power cable
