INSTALLATION
When you receive the scale, inspect it to make sure that it is not damaged and that all are
parts are included:
Ø Remove the Indicator from the carton.
Ø Remove the protective covering.
Ø Store the packaging and use if you need to transport the scale later.
Ø Inspect the indicator for damage.
Ø Make sure all components are included (pictured below):
These are: 1 x FWS 114 Stainless Steel Display
1 x Hydraulic Pressure Transducer
1 x Hydraulic Hose
1 x Hydraulic Male Adaptor 1/8 BSPT – 7/17JIC
1 x 3A Glass Fuse
1 x Glass Fuse in- line fuse holder
1 x Sticker set (3 pieces)
1 x Operator Handbook
