Description to accompany the installation plan
1
Electrical connection
Flexible, as per the connection diagramm
Options: Power shut-off kit
Potential-free ventilation contact
2
Main switch
3
Emergency stop button
4
Labels
Type labels, power rating plate, danger sign, service label
5
Exhaust air duct
Diameter 200 mm
Option: 160 mm
Exhaust air volume D 200: max. 480 m
3
/ h
D 325: max. 840 m
3
/ h
Exhaust air temperature max. 70 °C
Resistance in the installation
supplied by the customer
D 200: max. 200 Pa
D 325: max. 200 Pa
6
Fresh air intake
(option)
Max intake temperature 40 °C
II the input temperature is below 10 °C, the drying performance is reduced.
Option: Fresh air connection ø 160 mm / ø 200 mm
7
Door hinging
left-hinged
Option: right-hinged (to be specified at the time of border)
8
Drawer for filter cleaning
Option: lockable drawer
9
Minimum size
50 mm on both sides, 500 mm on the back of the machine
10
Socle
(option)
Height: 270 mm
