washMaster Installation guide
539715.AB Page 19 / 21 07.2019
7 Installing the washMaster module
The work may only be carried out by a specialist!
Opening the machine and removing the cover is described in the service manual.
7.1 Procedure for appliances with machine number > 0xxxx 18 38 xxx
7.1.1 Installing the WashMaster ID Reader
The installation of the
washMaster ID Reader (539 462) in the machine is described in the
Service Manual (see section “Removing / Installing an additional panel”).
7.1.2 Installing the antenna in the machine
Washing machine
Insert antenna holder Glue the antenna
Dryer
Insert antenna Glue the antenna
