SCHUNK FT - Page 32

Technical data
32 03.00 | FT | Assembly and Operating Manual | en | 389582
Mini45-Titan
Calibration F
x
/ F
y
[N]
F
z
[N]
M
x
/ M
y
[Nm]
M
z
[Nm]
F
x
/ F
y
[N]
F
z
[N]
M
x
/ M
y
[Nm]
M
z
[Nm]
SI-60-3 60 120 3 3 1/60 7/240 3/8000 1/3200
SI-120-6 120 240 6 6 1/30 7/120 3/4000 1/1600
SI-240-12 240 480 12 12 1/15 7/60 3/2000 1/800
Ranges of measurement FTD, FTN, FTW, FTE resolution
