Technical data
Mini45 (including IP 65 and IP 68)
Calibration F
x
/ F
y
[N]
F
z
[N]
M
x
/ M
y
[Nm]
M
z
[Nm]
F
x
/ F
y
[N]
F
z
[N]
M
x
/ M
y
[Nm]
M
z
[Nm]
SI-145-5 145 290 5 5 1/16 1/16 1/752 1/1504
SI-290-10 290 580 10 10 1/8 1/8 1/376 1/752
SI-580-20 580 1160 20 20 1/4 1/4 1/188 1/376
Ranges of measurement FTD, FTN, FTW, FTE resolution
