Assembly
20 210.00 | PZN-plus | Assembly and Operating Manual | en | 389374
5 Assembly
5.1 Installing and connecting
DANGER
Danger of explosion in potentially explosive areas!
l
Observe supplementary sheet for products with explosion-
resistant versions "PZN-plus -...-EX".
WARNING
Risk of injury due to unexpected movements!
If the power supply is switched on or residual energy remains in
the system, components can move unexpectedly and cause
serious injuries.
l
Before starting any work on the product: Switch off the power
supply and secure against restarting.
l
Make sure, that no residual energy remains in the system.
CAUTION
Damage to the gripper is possible!
If the maximum permissible finger weight or the permissible
mass moment of inertia of the fingers is exceeded, the gripper
can be damaged.
l
A jaw movement always has to be without jerks and bounce.
l
You must therefore implement sufficient reduction and/or
damping.
l
Observe the information in the catalog data sheet.
1. Check the evenness of the mounting surface, }5.2.1 [/21].
2. Only open the required air connections (main connection or
direct connection), }5.2.2 [/24].
3. Connect the product via the hose-free direct connection.
ð Use O-rings from the accessory pack.
ð Seal main air connections which are not required with
locking screws.
4. OR: Connect compressed air lines to the main air
connections"A" and"B".
ð Screw in air connections (plug connections).
OR: Screw on throttle valve in order to be able to perform
sufficient throttling and/or damping.
5. Screw the product to the machine/system, }5.2.1 [/21].
