Schwing VECTOR User Manual

Service Manual
V
ECTOR
C
ONTROLLER
-S
ERVICE
M
ANUAL
13
Remote control
3
0
3
62
348
3035
6
534 C
5
4
3
2
1
0
1
0
9
8
7
6
1
2
3
RPM engine
(+) = up
(-) = down
Vehicle engine
(I) = on (starting)
(0) = off (stopping)
Control on
Diagnostic horn signal confirm
(shut-off)
Vehicle signal horn on
End hose shutoff valve
Ball injection system
Concrete pump delivery rate
(+) = increase
(-) = decrease
Vibrator in automatic mode(on)
Water pump
Agitator in:
( ) = forward
( ) = reverse
Concrete pump
forwards (pumping)
Concrete pump
reverse (suction)
(0)
boom speed slow
(placing operations)
boom functions off
boom speed fast
(set-up and take-down)
Radio remote control only:
LED:
charge condition of transmitter battery
LED:
tansmitter state of operation:
continuously on = transmitter ready
flashing = transmitting control
signals
