VECTOR CONTROLLER-SERVICE MANUAL 15
Menu overview - Main menu (continued)
Pumped Volume C
Pumped Volume Counter
Pumped on the job:
2.4 cbm
Reset ? - > [START]
Oper. Data! C
Oil Pressure CP
Oil Temperature
Oil Tank Level
PTO Hours
CP Hours
Boom Hours
69.8
64
---.-
33.84
0.09
0.10
bar
˚C
%
h
h
h
Oper. Data! C
Water Pump
Hp-Water Pump
Compressor
Agitator
Oilcooler
Vibrator
Hrs
Hrs
Hrs
Hrs
Hrs
Hrs
0.00
0.00
0.00
0.05
33.51
0.00
h
h
h
h
h
h
Oper. Data! C
Pumped Vol.
Pumped Vol.
Strokes CP
Stroke Rate
Central Lubr.
Job
Ttl
Ttl
CP
Hrs
2.4
3.0
40
00.0
0.00
cbm
cbm
st/m
h
Oper. Data! C
! Hours when moving !
Boom
Slewing
Outrigger
0.00
0.00
0.00
h
h
h
Start
Malfunct.List! C
Malfunction List
! n/a !!
Start
OK
1
0
2
3
PTO
1500 rpm
x1000
Pumped Volume?
OK
1
0
2
3
PTO
1500 rpm
x1000
Malfunct.List?
OK
1
0
2
3
PTO
1500 rpm
x1000
Oper.Data?
Status-Screen?
I/O-Readout?
