Service Manual
40 VECTOR CONTROLLER-SERVICE MANUAL
S07L
F 20
Fuse F 20 Fault !
S08L
F 16
Fuse F 16 Fault !
S09L
F 31
Fuse F 31 Fault !
S10L
F 32
Fuse F 32 Fault !
S11L
MF1
MF1 : Power Supply
Diagnosis E-Stop Board
DI15 - DI18 Fault !
S12L
MF2
MF2 : Power Supply
Truck Interface etc.
DI21 - DI27 Fault !
S13L
MF3
MF3 : Power Supply
DI28,DI38,DI46,DI48
Fault !
S14L
MF4
MF4 : Power Supply
DI31-DI37,DI43,DI44
Fault !
S15L
MF5
MF5 : Power Supply
DI36,DI37,DI45
Fault !
S16L
MF6
MF6 : Power Supply
DI41,DI42,DI47,AI21,AI22
Fault !
S17L
MF7
MF7 : Power Supply
RAM-Change Station
DI51-DI54 Fault !
S18L
MF8
MF8 : Power Supply
DI55 - DI58
Fault !
