32
8. 5HPRYHWKH0DVW*DVNHW6HWLWVDIHO\DVLGHIRU
reassembly.
9. Bend the edges of the Top Shroud to disengage the in-
side tabs from the Main Assembly, and slide the Top Shroud
up the Mast.
10. 5HPRYHWKHKDUGZDUHLQGLFDWHGIURPWKH0DVW*HQWO\
pull the Mast out and disconnect the cables. Set the hard-
ware, Mast and Top Shroud safely aside.
NOTICE: Do not cut or pinch the cables. This step may
require two people.
Note: Do not let the cable fall down inside the Frame.
X2
