Console Setup Mode – 170 / 270 series (MY17) Console
The Console Setup Mode lets you input the date and time, set the units of measurement to either English or Metric,
FRQWUROWKHVRXQGVHWWLQJVRQRႇRUVHHPDLQWHQDQFHVWDWLVWLFV7RWDO5XQ+RXUV±IRUVHUYLFHWHFKQLFLDQXVHRQO\
1. Hold down the PAUSE/END button and Right button together for 3 seconds while in the Power-Up Mode to go into
the Console Setup Mode.
Note: Push PAUSE/END to exit the Console Setup Mode and return to the Power-Up Mode screen.
2. The Console display shows the Date prompt with the current setting. To change, push the Increase/Decrease buttons
WRDGMXVWWKHFXUUHQWO\DFWLYHYDOXHÀDVKLQJ3XVKWKH/HIW5LJKWEXWWRQVWRFKDQJHZKLFKVHJPHQWLVWKHFXUUHQWO\
active value (month / day / year).
3. Push OK to set.
4. The Console display shows the Time prompt with the current setting. Push the Increase/Decrease buttons to adjust
WKHFXUUHQWO\DFWLYHYDOXHÀDVKLQJ3XVKWKH/HIW5LJKWEXWWRQVWRFKDQJHZKLFKVHJPHQWLVWKHFXUUHQWO\DFWLYHYDOXH
(hour / minute / AM or PM).
5. Push OK to set.
6. The Console display shows the Units prompt with the current setting. To change, push OK to start the Units option.
Push the Increase/Decrease buttons to change between “MILES” (Imperial English units) and “KM” (metric units).
Note: If the units change when there is data in User Statistics, the statistics convert to the new units.
7. Push OK to set.
8. The Console display shows the Sound Settings prompt with the current setting. Push the Increase/Decrease buttons
to change between “ON” and “OFF”.
9. Push OK to set.
10. The Console display shows the TOTAL RUN HOURS for the machine.
 7RJRWRWKHQH[W&RQVROH6HWXS0RGHSURPSWSXVKWKH2.EXWWRQ*RWRVWHS
11. The Console display shows the Software Version prompt. Push OK to go to the next prompt.
 5($',1*%/(±7KH&RQVROHGLVSOD\VKRZVWKH%OXHWRRWK
®
reading string.
 ',6&211(&7%/(B12±3XVKWKH,QFUHDVH'HFUHDVHEXWWRQVWRDGMXVWWKHYDOXH12<(63XVK2.WRVHW
Condition/Problem Things to Check Solution
Clicking sound when
pedaling
Check pedal to crank arm
connection
Remove pedals. Make sure there is no debris on threads, and
reinstall the pedals
Seat post movement Check locking pin Be sure adjustment pin is locked into one of the seat post
adjustment holes.
Check adjustment knob Be sure knob is securely tightened.
Workout results will not
sync with Bluetooth
®
en-
abled device
Current console mode Machine must be in Idle Mode to sync. Push the PAUSE/STOP
button until the Power-Up Mode screen is displayed.
Total time of workout A workout must be longer than 1 minute to be saved and
posted by the Console.
Fitness machine Unplug unit from electrical outlet for 5 minutes. Reconnect to
outlet.
Bluetooth
®
enabled device Consult your device to be sure that the Bluetooth
®
wireless
feature has been enabled on it.
Fitness App 5HYLHZ6SHFL¿FDWLRQVRI)LWQHVV$SSDQGFRQ¿UP\RXUGHYLFH
is compatible.
Contact appsupport@nautilus.com (if inside US/Canada)
or your local distributor (if outside US/Canada) for further
assistance.
