Section 1 - Replacing the O󰀪ine Power Supply
to Sensor Hub (DC Power) and/or Lift Motor
Control Cables
Make sure that power to the machine is discon-
nected before beginning this step.
1. Using a 4 mmhexwrench,removethe4screws
(indicatedbycircles)thatsecuretheO󰀪inePowerSupply
Cover, and remove it.
Sensor Hub
O󰀪inePower
Supply
Note: Main Shrouds removed for clarity.
O󰀪ine
Power
Supply
Cover
