SCION xA (EM00D0U)
59
:
Junction Block and Wire Harness Connector
Code See Page Junction Block and Wire Harness (Connector Location)
10
1A
24
Engine Room Main Wire and Instrument Panel J/B (Lower Finish Panel)
1B
24
Engine Room Main Wire and Instrument Panel J/B (Lower Finish Panel)
1D
25
Instrument Panel Wire and Instrument Panel J/B (Lower Finish Panel)
1E
25
Instrument Panel Wire and Instrument Panel J/B (Lower Finish Panel)
1F
25
Instrument Panel Wire and Instrument Panel J/B (Lower Finish Panel)
1G
25
Instrument Panel Wire and Instrument Panel J/B (Lower Finish Panel)
1H
25
Instrument Panel Wire and Instrument Panel J/B (Lower Finish Panel)
1O
1P
1T 24 Floor Wire and Instrument Panel J/B (Lower Finish Panel)
:
Connector Joining Wire Harness and Wire Harness
Code See Page Joining Wire Harness and Wire Harness (Connector Location)
EA1 34 Engine Wire and Sensor Wire (Near the Starter)
EB1 34 Engine Wire and Engine Room Main Wire (Inside of the Engine Room R/B)
IB1 36 Floor Wire and Instrument Panel Wire (Upper Side of the Instrument Panel J/B)
ID2
36
Engine Room Main Wire and Instrument Panel Wire (Upper Side of the Instrument Panel J/B)
ID3
36
Engine Room Main Wire and Instrument Panel Wire (Upper Side of the Instrument Panel J/B)
IF1
37
Engine Wire and Instrument Panel Wire (Left Side of the Blower Unit)
IF2
37
Engine Wire and Instrument Panel Wire (Left Side of the Blower Unit)
:
Ground Points
Code See Page Ground Points Location
EC 34 Cylinder Head
ED 34 Front Fender Apron LH
IE 36 Left Kick Panel
IF 36 Instrument Panel Brace LH
IG 36 Right Kick Panel
BH 38 Left Quarter Pillar
