SCION xA (EM00D0U)
161
J
Fuse System Page
10A TAIL
Light Reminder
Taillight and Illumination
122
70
15A ACC
Audio System
Cigarette Lighter
Remote Control Mirror
132
126
124
15A FOG Front Fog Light 62
25A DEF Rear Window Defogger 130
25A D/L Door Lock Control 86
25A WIPER
Front Wiper and Washer
Rear Wiper and Washer
78
80
30A POWER
Power Window
Sliding Roof
82
114
40A HTR
Air Conditioning
PTC Heater
Two Way Flow Heater
150
146
142
Engine Room R/B (See Page 22)
Fuse System Page
10A H–LP LH/H–LP LO LH Headlight 60
10A H–LP RH/H–LP LO RH Headlight 60
15A AM2
ABS (w/ VSC), TRAC and VSC
ABS (w/o VSC)
Charging
Combination Meter
Electronically Controlled Transmission and A/T Indicator
Engine Control
SRS
Starting and Ignition
96
106
50
136
90
52
109
46
15A DOME
Audio System
Combination Meter
Interior Light
Key Reminder and Seat Belt Warning
Light Reminder
132
136
68
120
122
15A EFI
Electronically Controlled Transmission and A/T Indicator
Engine Control
90
52
15A HORN Horn 128
30A RDI Radiator Fan and Condenser Fan 148
30A ST Starting and Ignition 46
40A ABS NO.1
ABS (w/ VSC), TRAC and VSC
ABS (w/o VSC)
96
106
50A HTR SUB1 PTC Heater 146
∗ These are the page numbers of the first page on which the related system is shown.
To Next Page
