SCION xA (EM00D0U)
J POWER SOURCE (Current Flow Chart)
Fusible Link Block (See Page 23)
Fuse System Page
60A ABS
ABS (w/ VSC), TRAC and VSC
ABS (w/o VSC)
96
106
60A MAIN
ABS (w/ VSC), TRAC and VSC
ABS (w/o VSC)
Charging
Combination Meter
Electronically Controlled Transmission and A/T Indicator
Engine Control
SRS
Starting and Ignition
96
106
50
136
90
52
109
46
120A ALT
ABS (w/ VSC), TRAC and VSC
ABS (w/o VSC)
Charging
96
106
50
∗ These are the page numbers of the first page on which the related system is shown.
