GB–8
MAIN UNIT
1. ON/OFF – Turn the player on or off.
2. PUSH OPEN – Open the disc door.
3. PLAY – Start disc playback or pause the playback.
4. STOP – Stops disc playback.
5. SKIP + – Skip to the next track, and next chapter ( only while playing )
6. SKIP - – Skip to the beginning / previous track (only while playing)
7. MENU – In DVD mode, press for Menu setup for DVD ( if available ). Switch PBC ON/OFF (For
VCD/SVCD)
8. SCREEN MODE – Press to select the screen display format between 16:9 and 4:3.
9. NAVIGATION ( / / / ) – Select Menu items
10. OK – Press to confirm the selected function.
11. SETUP – Accesses the DVD player setup menu.
12. DISPLAY – Press for detailed information on the disc playing.
13. VOLUME – Adjust the volume to the desired level using the dial.
14. HEADPHONE JACK – Listen to stereo sound with headphones (included)
15. VIDEO
Video out – Connects to the Video input to your TV. ( A/V Switch set at “ OUT ” )
Video in – Connects to the Video from external video source. ( A/V Switch set at “ IN ” )
16. AUDIO
Audio Out – Connects to the Audio input to your TV/External amplifier system. ( A/V Switch
set at “ OUT ” )
Audio In – Connects to the Line OUT from external audio source. ( A/V Switch set at “ IN ” )
17. A/V IN/OUT – Switch between analog Audio and Video IN / OUT function.
18. DC IN – Connects to DC power source in
19. IR – Infrared sensor for remote control.
20. POWER LED – Led lights up when the player turns on.
21. CHARGE LED – Led blinks in red when the battery is being charged; LED lights in red when
the battery is charged full.
22. SPEAKERS
23. MODE – Select disc or media (USB or SD/MMC card).
24. S-VIDEO – S-Video output to your TV.
25. USB – USB socket.
26. CARD – SD/MMC card slot.
