RECOMMENDED TORQUE SETTINGS FOR DISC BRAKES ON YOUR
SCOTT BIKE
Component Shimano
1
Avid
2
Tek tro
3
TRP
4
Magura HS
5
(Nm) (Nm) (Nm) (Nm) (Nm)
Brake calliper mount 6 - 8 9 - 10 6 - 8 6 - 8 6
on frame/fork (IS adapter)
8 - 10
(brake calliper)
Brake lever unit on handlebars
- Single-bolt clamp 6 - 8 Discrete Clamp Bolt/ 5 - 7 4
Hinge Clamp Bolt/
XLoc Hinge Clamp Bolt: 5 - 6
Pinch Clamp Bolt: 2.8 - 3.4
Split Clamp Bolts/
Match Maker Bolts: 3 - 4
- Two-bolt clamp 4 - 5
Union screws of cable 5 - 7 5 4
at grip and normal cable
at brake calliper
Brake cable connector at 5 - 7
brake calliper (disc tube cable)
Expansion tank cap 0.3 - 0.5
Bleeding device brake calliper 4 - 6 4 - 6
Bleeding device brake lever 2 - 4
Brake disc fixing 4 6.2 4 - 6 6 - 8
(6-holes)
Brake disc fixing 40
(centerlock)
Hose (union nut) direct connection 4
Slave cylinder (bleeder screw) 4
Brake pad retainer at brake calliper 3 - 5
Cable clamp at brake calliper 4 - 6
1
www.shimano.com
2
www.sram.com
3
www.tektro.com
4
www.trpbrakes.com
5
www.magura.com
These values are reference values of the above-mentioned component manu-
facturers. Observe the values in the manuals of the component manufacturers
on the enclosed SCOTT info CD. These values do not apply to the components
of other manufacturers.
NOTE!
I
Due to the unmanageable number of components on the market, SCOTT
is not in a position to foresee every product that will be replaced or newly
assembled by third parties. Therefore SCOTT denies any liability for such kind
of additions or modifications with regard to compatibility, torque values etc.
Whoever assembles or modifies the SCOTT bike shall ensure that the bike was
assembled according to the state-of-the-art in science and technology.
RECOMMENDED TORQUE SETTINGS FOR YOUR SCOTT BIKE
All bolted connections of the bike components have to be tightened carefully
and checked regularly to ensure the safe and reliable operation of the SCOTT
bike. This is best done with a torque wrench that disengages as soon as the
desired torque value has been reached or a click-type torque wrench. Tighten
carefully by approaching the prescribed maximum torque value in small steps
(0.5 Nm increments) and check in between the proper fit of the component.
Never exceed the maximum torque value indicated by the manufacturer!
Where no maximum torque setting is given start with 2 Nm. Observe the indi-
cated values and observe the values on the components and/or in the manuals
of the component manufacturers on the enclosed SCOTT info CD.
Component Bolted connections Shimano
1
SRAM/Avid
2
Tek tro
3
TRP
4
(Nm) (Nm) (Nm) (Nm)
Rear derailleur Mount 8 - 10 8 - 10
(on frame/derailleur hanger)
Cable clamp 5 - 7 4 - 5
Pulley wheels 3 - 4
Front Mount on frame 5 - 7 5 - 7
derailleur Cable clamp 5 - 7 5
Shifter Mount on handlebars 5 2.5 - 4
Hole covering 0.3 - 0.5
Brake lever Mount on handlebars 6 - 8 5 - 7 6 - 8
unit Time trial brake lever 5 - 7
Hub Quick-release lever 5 - 7.5
Lock nut for bearing adjustment
Of quick-release hubs 10 - 25
Sprocket cluster lock ring 29 - 49 40
Internal Hub axle nut 30 - 45
gear hub
Crank Crank mount (grease-free square-head) 35 - 50
Crank mount (Shimano Octalink) 35 - 50
Crank mount
(Shimano Hollowtech II) 12 - 15
Crank mount (Isis) 31 - 34
Crank mount (Giga X Pipe) 48 - 54
Chainwheel mount 8 - 11 12 - 14 (steel)
8 - 9 (alu)
Sealed Shell (square-head) 49 - 69
cartridge Shell (Shimano Hollowtech II, 35 - 50
bearing SRAM Giga X Pipe) 34 - 41
Shimano Octalink 50 - 70
Pedal Pedal axle 35
Shoe Cleat 5 - 6
Spike 4
Brake Cable clamp 6 - 8 6 - 8 6 - 8 6 - 8
(V-brake) Brake shoe mount 6 - 8 6 - 8 6 - 8 6 - 8
Brake pad fixing 1 - 2
Brake boss frame/fork 8 - 10
1
www.shimano.com
2
www.sram.com
3
www.tektro.com
4
www.trpbrakes.com
