SDMO Nexys 2 User Manual

13/22 Ref. GPAO : 33502017201_1_1
4.3. List of faults which will cause the generating set to stop and generate a pictogram
Oil pressure fault: Indicates that the oil pressure is
incorrect
Associated pictogram
Engine temperature fault: Indicates that the engine
temperature is too high.
Associated pictogram
Non-starting fault: Indicates that there have been three
consecutive unsuccessful starting attempts.
Associated pictogram
Overspeed fault: Indicates an excessive generating set
running speed.
Associated pictogram
Low fuel level fault: Indicates the need to top up the fuel.
Associated pictogram
