16/22 Ref. GPAO : 33502017201_1_1
y Low fuel level
The low fuel level pictogram flashes if the low fuel level has been configured as an alarm.
The low fuel level pictogram lights up and remains lit if the low fuel level has been configured as a fault. In this case, the general
fault LED flashes red.
y Screen display when pictograms appear
If there is no screen display when the pictograms below appear, this displays that the transmitter is disconnected.
Example:
No display opposite the "coolant temperature" pictogram means that the
transmitter is disconnected.
y Coolant temperature
If the coolant temperature falls below 30°C or rises above 120°C, the display will flash at a value of 30°C or 120°C respectively.
y LCD screen
The LCD screen lights up:
¾ Permanently whilst the generating set is starting up or operating
¾ For 5 minutes:
o Following the appearance of an event when the generating set is in stop mode (an event may be a fault, an alarm
or one of the 3 control buttons being pressed)
o Following a normal stop of the generating set by means of pressing the "STOP" button or if the external
command disappears
