9. Fault finding
Probable causes Remedial action
The generating set is being charged during start-up Take it off charge
Fuel level too low Fill up with fuel
The fuel tap is closed Open the fuel tap
Fuel supply blocked or leaking Have the system repaired
Blocked air filter Clean the air filter
The engine will
not start
Control on "STOP" Place the control on "RUN"
Probable causes Remedial action
Blocked ventilation inlets Clean the air inlet and outlet guards
The engine cuts
out
Probable overcharge Check the charge
Probable causes Remedial action
Circuit-breaker tripped Reset the circuit breaker
Circuit-breaker faulty Have it checked, repaired or replaced
Faulty socket Have it checked, repaired or replaced
Faulty appliance supply lead Change the lead
No electric
current
Faulty alternator Have it checked, repaired or replaced
Probable causes Remedial action
Circuit breaker
trips out
Faulty equipment or lead Have it checked, repaired or replaced
10. Specifications
Model SD 4000
Motor type Yanmar L 70
Output 50 Hz (watts) 3200
Current 230 V – 13.9 A
Socket type 2 x 10 / 16 A
Circuit breaker ●
EEC noise level rating (LWA) 99
Weight in kg (without fuel) 73
Dimensions l x w x h in cm 87 x 56 x 56
Recommended oil SAE 15W40
Oil sump capacity in L 1.1
Recommended fuel Diesel fuel
Fuel tank capacity in L 12
●: standard ○: optional X: not possible
11. Cable sizes
Cable lengths Rated current
(A)
0 – 50 metres 51 – 100 metres 101 – 150 metres
6 1.5 mm
2
1.5 mm
2
2.5 mm
2
8 1.5 mm
2
2.5 mm
2
4.0 mm
2
10 2.5 mm
2
4.0 mm
2
6.0 mm
2
12 2.5 mm
2
6.0 mm
2
10.0 mm
2
16 2.5 mm
2
10.0 mm
2
10.0 mm
2
18 4.0 mm
2
10.0 mm
2
10.0 mm
2
24 4.0 mm
2
10.0 mm
2
16.0 mm
2
26 6.0 mm
2
16.0 mm
2
16.0 mm
2
28 6.0 mm
2
16.0 mm
2
16.0 mm
2
