IDS701 User Manual
Page 16 of 25
Baud rate
0=1200/1=2400/2=4800/3=9600
Zero range
C20
Manually zero
range
option：0= close manually zero setting
1=±1% max capacity
2=±2% max capacity
4=±4% max capacity
C21
Initical zero range
option：0= no initial zero
1=±1% max capacity
5=±5% max capacity
10=±10% max capacity
20=±20% max capacity
Automatic
zero tracking
C22
Automatic zero
tracking range
option：0.0= close automatic zero
tracking
0.5=±0.5d
1.0=±1.0d
2.0=±2.0d
3.0=±3.0d
4.0=±4.0d
5.0=±5.0d
remark：1.d is the set graduation
2、Automatic zero tracking
range can not exceed manual
zero setting range
C23
Automatic zero
tracking time
option：0= close automatic zero
tracking time
1=1 second
2=2 seconds
3=3 seconds
Overload
C24
option：00= close overload range
