2
R1503motr269B
1
TYPICAL
1. Air intake hose
2. Throttle body
Open the throttle body valve by press-
ing slightly the throttle lever.
Spray XP-S LUBE lubricant through the
thrott le body bore to lubricate valve
mechanism.
R1503motr165B
2
1
TYPICAL
1. Open throttle body valve
2. Lubricate valve mechanism
Reinstall a ir intake hose.
Electrical Connections
As necessary, apply anticorrosion
product such as dielectric grease on
battery posts and all exposed cable
connectors.
CAUTION: Do not lubricate connec-
tors of the Multi-Purpose Electron-
ic Module (MPEM) and the engine
Electronic Control Module (ECM).
Additional Lubrication
XP-S LUBE or equivalent will help pre-
vent corrosion of metallic parts and
maintain proper operation of moving
mechanisms.
WARNING
Do not lubricate the safety lanyard
post.
Ski/Wak eboard Post (if so equipped)
Lubricate ski/wakeboard post through
all its length. Pull out then push in sev-
eral times to distribute the lubricant.
Reverse Gate
Lubricate pivoting points and mecha-
nism.
Throttle Cable Inspection
Throttle Cable
Depress and release the throttle lever.
It should operate smoothly and return
to its initial position without any hesi-
tation. There must be a small amount
of free-play when throttle lever is re-
leased. Refer to an authorized Sea-
Doodealerifnecessary.
CAUTION: Never attempt to adjust
the idle speed through the throttle
body tamper proof screw. If so, it
wou ld impair th e idle spee d stabil-
ity. Besides, no adjustment could
be performed by the dealer nor the
factory to correct the idle speed.
The throttle body w ould need to
be replaced at the customer's ex-
pense. Also take into account that
might change the engine emission
level and the engine might not meet
the EPA/CARB requirements.
WARNING
Do not alter or tamper with throttle
cable adjustment or routing.
_____________________
95
