52
Stern Eyelet
Some Models
This eyelet allows a rope with a hook,
a closed end or an open end to be at-
tached.
1. Stern eyelet
30) Mooring Cleats
All Models except XP
These cleats can be temporarily used for
docking, while refueling for example.
CAUTION: Never use mooring cleats
to pull or lift the watercraft.
1. Mooring cleats
XP Models
1. Mooring cleats
31) Footboard
User’s feet should rest on the footboard
when riding.
32) Boarding Pads
Provide a cushioned surface for the
knees when boarding from rear of wa-
tercraft.
All Models
33) Boarding Platform
Provides a large surface for easier board-
ing from rear of watercraft.
34) Boarding Step
(if so equipped)
A convenient step to help reboarding
the watercraft.
1. Boarding step
F07L0YY
1
F00L0DY
1
F08L0TZ
1
F07L1HY
1
smo2002-002b.fm Page 52 Friday, December 7, 2001 2:53 PM
