SeaDoo GTX 4-TEC User Manual

26
1. Safety Lanyard
(engine cut-off cord)
2. Handlebar
3. Throttle Lever
4. Engine Start/Stop Button
5. Shift Lever
6. Speedometer
7. Tachometer
8. Information Center Gauge/Buttons
9. Glove Box
10. Fuel Tank Cap
11. Front Storage Compartment Cover
12. Front Storage Compartment Cover
Latch
13. Tool Kit
14. Air Intake Opening
15. Seat Strap
16. Seat Extension Latch
17. Seat Latch
18. Rear Grab Handle
19. Rear Storage Basket
20. Front and Rear
(bow/stern) Eyelets
21. Mooring Cleats
22. Footboard
23. Boarding Pads
24. Boarding Platform
25. Boarding Step
26. Flushing Connector
27. Bilge Drain Plugs
28. Jet Pump Nozzle
29. Reverse Gate
30. Jet Pump Water Intake
31. Fuses
32. Battery
33. Side Vanes
34. Engine Oil Dipstick
35. Engine Oil Filling Cap
36. Cooling System Expansion Tank
Cap
smo2002-003_a.book Page 26 Friday, October 12, 2001 2:04 PM

SeaDoo GTX 4-TEC Specifications

General

Manufacturer	Sea-Doo
Model	GTX 4-TEC
Category	Personal Watercraft
Displacement	1494 cc
Horsepower	155 hp
Fuel Type	Gasoline
Cooling	Closed-Loop Cooling System
Seating Capacity	3
Engine	4-TEC
Fuel Capacity	15.9 US gal
Width	48.0 inches
Length	130 in (330 cm)
