SeaDoo GTX 4-TEC User Manual

41
1. Fuses
32) Battery
Battery is located under seat in bilge.
Refer to SPECIAL PROCEDURES.
1. Battery
33) Side Vanes
Side vanes are part of the Off-Power As-
sisted Steering (O.P.A.S.™) system.
When engine RPM is reduced, the side
vanes are lowered to assist the steering
system. Refer to Principle of Operation
in OPERATING INSTRUCTIONS section
for the description of the system.
34) Engine Oil Dipstick
Located in engine compartment, on
the engine. It indicates the engine oil
level.
1
F18H0JY
1
F18H0AY

WARNING
Check handlebar and correspond-
ing side vanes operation before
starting. Never use side vanes as a
supporting point to board the wa-
tercraft or to lift it. Never turn han-
dlebar while someone is nearby
rear of watercraft. Keep away from
steering moving parts (nozzle,
side vanes, linkage etc.).

WARNING
Certain components in the engine
compartment may be very hot. Di-
rect contact may result in skin burn.
smo2002-003_a.book Page 41 Friday, October 12, 2001 2:04 PM

SeaDoo GTX 4-TEC Specifications

General

Manufacturer	Sea-Doo
Model	GTX 4-TEC
Category	Personal Watercraft
Displacement	1494 cc
Horsepower	155 hp
Fuel Type	Gasoline
Cooling	Closed-Loop Cooling System
Seating Capacity	3
Engine	4-TEC
Fuel Capacity	15.9 US gal
Width	48.0 inches
Length	130 in (330 cm)
