29
CAUTION: Never rev the engine at
high RPM in reverse.
From the forward position, pull the le-
ver to reverse. Push back to go to for-
ward. Always set in forward when fin-
ished. To find the neutral, set in reverse
then push back until the watercraft
stops moving backwards.
1. Forward position
1. Neutral position
1. Reverse position
6) Speedometer
Analog speedometer indicates the
speed of watercraft in miles per hour
(MPH) and kilometers per hour (km/h).
The speed sensor mounted on the
transom sends the signal to the infor-
mation center.
7) Tachometer
An analog tachometer indicates the
revolutions per minute (RPM) of the
engine. Multiply by 1000 to obtain the
actual revolutions.
8) Information Center
Gauge/Buttons
This is a multifunction gauge that sup-
plies several real time useful informa-
tion to the driver.
Components Description
1. Speedometer
2. Tachometer
3. Display area
WARNING
Only use reverse at slow speed and
for the shortest time possible. Al-
ways ensure the path behind is clear
of objects and persons including
children playing in shallow water.
1
F18J01Y
F18J02Y
1
F18J03Y
1
F18H08Y
3
1 2
smo2002-003_a.book Page 29 Friday, October 12, 2001 2:04 PM
