50
OPERATING INSTRUCTIONS
Principle of Operation
Propulsion
The engine is directly coupled to a
drive shaft which, in turn, rotates an
impeller. This impeller is accurately ad-
justed in a housing where the water is
drawn up from underneath the water-
craft. Then the water flows through
the impeller to a venturi. The venturi
accelerates the water and produces
thrust to move the watercraft. De-
pressing the throttle lever increases
engine speed and therefore watercraft
speed.
TYPICAL
The shift lever should be in the forward
position in order for the watercraft to ad-
vance.
Neutral and Reverse
To find the neutral, set in reverse then
push back until the watercraft stops
moving backwards.
The reverse gate will be in the middle
position, directing half of the thrust to-
ward the front of the watercraft to min-
imize watercraft movement.
WARNING
Always perform the PRE-OPERATION
CHECKS before operating the water-
craft. Become thoroughly familiar
with all controls and the function of
each. Should any control or instruc-
tion not be fully understood, refer to
an authorized Sea-Doo dealer.
WARNING
Whenever the engine is to be start-
ed, the operator and passenger(s)
should always be properly sitting
on the watercraft and be wearing
protective clothing including a Coast
Guard approved PFD and a wet suit
bottom.
F18J06Y
WARNING
Keep away from intake grate while
engine is on. Items such as long
hair, loose clothing or personal flo-
tation device straps can become
entangled in moving parts result-
ing in severe injury or drowning.
WARNING
Never use jet pump components as
a supporting point to board the wa-
tercraft. Shift lever should only be
used when the engine is idling and
watercraft is completely stopped.
Never rev the engine at high RPM
in reverse. Do not use reverse to
stop the watercraft. Only use re-
verse at slow speed and for the
shortest time possible. Always en-
sure the path behind is clear of ob-
jects and persons including chil-
dren playing in shallow water.
WARNING
When the watercraft is in neutral
position, the drive shaft and impel-
ler are still turning.
smo2002-003_a.book Page 50 Friday, October 12, 2001 2:04 PM
