71
MPEM
To access fuses on the MPEM, remove
seat.
Locate MPEM besides engine.
1. Fuses
Fuses rating are identified, look besides the fuse holders.
FUSE IDENTIFICATION
1
F18H0JY
10A
2A
10A
1A
10A
10A
3A
5A
10A
2A
7.5A
5A
F18H07L
Spare
T.O.P.S.
Cylinder 3
ignition coil
and injection
Information
center
EMS
start/stop circuit
VTS
(optional)
MPEM
Electric starter,
fuel pump
Bilge pump
(optional)
Beeper
diagnostic,
connector
Cylinder 2
ignition coil
and injection
Cylinder 1
ignition coil
and injection
Spare fuse
smo2002-003_a.book Page 71 Friday, October 12, 2001 2:04 PM
