23QB218 6.1.2019 vers 1.0
6. Check this area for any jammed coins
Removal of Coin Changer
To Remove the Coin Changer:
a. Disconnect the power to the machine – this is very important to avoid damaging not only the coin changer
but your VMC. Failure to disconnect power before performing this operation will void your warranty.
b. Disconnect the Wire Harness to the changer
Disconnect Wire
Harness
