Seaga Quick Break Combo QB218 - Preliminary Information

4QB218 6.1.2019 vers 1.0
Preliminary Informaon
Figure 1 – The QB218 Vending System
Main Unit - VMC
Aux Unit
oponal
Display
Window
Aux. Display
Window
Display
Product Delivery
Door
Main Door
Handle and Lock
Display
Window
Product Delivery
Door
Aux Product Delivery
Door
Aux. Door
Handle and Lock
keypad
