Seagate BARRACUDA 2LP - Figure 6. Air Flow Pattern (ST32550 N Drive Shown)

Barracuda 2LP Product Manual, Rev. D 23
Above unit
Under unit
Note. Air flows in the direction shown (back to front)
or in reverse direction (front to back)
Above unit
Under unit
Note. Air flows in the direction shown or
in reverse direction (side to side)
Figure 6. Air-flow pattern (ST32550N drive shown)
