Seagate Exos 7E10 Serial ATA Product Manual, Rev. B 5
1.0 Introduction
This manual describes the functional, mechanical and interface specifications for the following:
Seagate® Exos™ 7E10 Serial ATA model drives:
These drives provide the following key features:
• 7200 RPM spindle speed.
• Full-track multiple-sector transfer capability without local processor intervention.
• High instantaneous (burst) data-transfer rates (up to 600MB per second).
• Native Command Queuing with command ordering to increase performance in demanding applications.
• Perpendicular recording technology provides the drives with increased areal density.
• PowerChoice™ for selectable power savings
• SeaTools™ diagnostic software performs a drive self-test that eliminates unnecessary drive returns.
• State-of-the-art cache and on-the-fly error-correction algorithms.
• Support for S.M.A.R.T. drive monitoring and reporting.
• Supports latching SATA cables and connectors.
• Tarnish-resistant components to help protect drive from environmental elements, increasing field reliability.
• Worldwide Name (WWN) capability uniquely identifies the drive.
512e/4kn models
Standard SED ISE FIPS Non-Mirrored
ST10000NM017B ST10000NM019B ST10000NM023B ST10000NM021B ST10000NM025B
ST8000NM017B ST8000NM019B ST8000NM023B ST8000NM021B ST8000NM025B
ST6000NM019B ST6000NM021B ST6000NM025B ST6000NM023B ST6000NM027B
ST4000NM024B ST4000NM026B ST4000NM030B ST4000NM028B
ST2000NM017B ST2000NM019B
4KN models
Standard SED ISE
ST10000NM002B ST10000NM006B ST10000NM014B
ST8000NM002B ST8000NM006B ST8000NM014B
ST6000NM004B ST6000NM008B ST6000NM016B
ST4000NM004B ST4000NM010B ST4000NM022B
ST2000NM004B ST2000NM010B ST2000NM014B
Note
Seagate recommends validating the configuration with the selected HBA/
RAID controller manufacturer to ensure use of full capacity is supported.
