Seagate ST1000VM002 - Acoustics and Electromagnetic Compatibility

Seagate Video 3.5 HDD Product Manual, Rev. A 17
www.seagate.com
2.10.1 Test for Prominent Discrete Tones (PDTs)
Seagate follows the ECMA-74 standards for measurement and identification of PDTs. An exception to this process
is the use of the absolute threshold of hearing. Seagate uses this threshold curve (originated in ISO 389-7) to
discern tone audibility and to compensate for the inaudible components of sound prior to computation of tone ratios
according to Annex D of the ECMA-74 standards.
2.11 Electromagnetic immunity
When properly installed in a representative host system, the drive operates without errors or degradation in
performance when subjected to the radio frequency (RF) environments defined in the following table:
2.12 Reliability - Annualized Failure Rate
The product will achieve an Annualized Failure Rate (AFR) of 0.55% when operated in an environment of ambient
air temperatures of 25°C. Operation at temperatures outside the specifications shown in Section 2.9 may increase
the product AFR. AFR is a population statistics that is not relevant to individual units.
• AFR specifications are based on the following assumptions for consumer electronics environments:
• 8760 power-on-hours per year
• 10,000 average motor start/stop cycles per year
• Operations at nominal voltages
• Temperatures outside the specifications in Section 2.9 may reduce the product reliability.
• Normal I/O duty cycle for consumer electronics environments. Operation at excessive I/O duty cycle may
degrade product reliability.
The consumer electronics environment of power-on-hours, temperature, and I/O duty cycle affect the product AFR.
The AFR will be degraded if used in an enterprise application.
Table 4 Radio frequency environments
Test Description
Performance
Level
Reference
standard
Electrostatic discharge Contact, HCP, VCP: ± 4 kV; Air: ± 8 kV B EN61000-4-2: 95
Radiated RF immunity
80MHz to 1,000MHz, 3 V/m,
80% AM with 1kHz sine
900MHz, 3 V/m, 50% pulse modulation @ 200Hz
A
EN61000-4-3: 96
ENV 50204: 95
Electrical fast transient ± 1 kV on AC mains, ± 0.5 kV on external I/O B EN61000-4-4: 95
Surge immunity ± 1 kV differential, ± 2 kV common, AC mains B EN61000-4-5: 95
Conducted RF immunity 150kHz to 80MHz, 3 Vrms, 80% AM with 1kHz sine A EN61000-4-6: 97
Voltage dips, interrupts
0% open, 5 seconds
0% short, 5 seconds
40%, 0.10 seconds
70%, 0.01 seconds
C
C
C
B
EN61000-4-11: 94
