Product Manual - Hawk 1 Family SCSI-2 (Volume 1), Rev. D
_____________________________________________________________________________________
31
Figure 7.6-1b. Mounting configuration dimensions for "NC" model drives
A
F
D
E
C
[1]
[3]
B
G
J
H
K
[2]
Notes:

[1]




[2]




[3]


[4]

[5]
Inches Millimeters
5.74 
4.00 
1.62 

2.362
.620
4.000
.250
1.750
3.750
2.370
1.725
4.100
0.19 
0.015
0.181
145.80 
101.60 
41.15 

60.00 
15.75 
101.60 
6.35 
44.45 
95.25 
60.20 
43.82 
104.14 
4.83 
0.381
4.597
A
B
C

D
E
F
G
H
J
K
L
M
N
P
R
0.010
0.010
0.026
0.021
0.010
0.010
0.010
0.018
0.010
0.010
0.010
0.010
0.010
0.010

0.018
0.013
±
±
+
–
±
±
±
±
±
±
±
±
±
±
max
+
–
.25
.25
.66
.53
.25
.25
.25
.46
.25
.25
.25
.25
.25
.25

.45
.33
L
[4]
M
N
[4]
P
Mounting holes three on each side, 6-32 UNC. Max
screw length into side of drive 0.15 in. (3.81 mm).
Screw tightening torque 8.0 in-lb max with minimum
thread engagement of .12 in (3.00 mm).

Mounting holes four on bottom, 6-32 UNC. Max
screw length into bottom of drive 0.20 in. (5.08 mm).
Screw tightening torque 8.0 in-lb max with minimum
thread engagement of .12 in (3.00 mm).

Power and interface connections can extend past the
"A" dimension by 0.040 in (1.02 mm).

Decorative front panel.

Connector is centered (side to side) on drive within 
± 0.020 in (.508 mm).
R ST
±
±
+
–
±
±
±
±
±
±
±
±
±
±
max
+
–
R
Connector Centerline
[5]
Drive Centerline
