Seagate ST11200N - Page 76

Product Manual - Hawk 1 Family SCSI-2 (Volume 1), Rev. D
______________________________________________________________________________________
continued from previous page
Waveform Waveform
Description Symbol [1] Table [1] Typical Max.
Asynchronous Data Transfer Characteristics: (continued)
Next CDB Byte Access (Byte 2 of 10) T23.10.2 4.5-4 0.46 us 0.50 us
Next CDB Byte Access (Byte 3 of 10) T23.10.3 4.5-4 0.11 us 0.14 us
Next CDB Byte Access (Byte 4 of 10) T23.10.4 4.5-4 0.12 us 0.14 us
Next CDB Byte Access (Byte 5 of 10) T23.10.5 4.5-4 0.12 us 0.14 us
Next CDB Byte Access (Byte 6 of 10) T23.10.6 4.5-4 0.11 us 0.14 us
Next CDB Byte Access (Byte 7 of 10) T23.10.7 4.5-4 0.12 us 0.14 us
Next CDB Byte Access (Byte 8 of 10) T23.10.8 4.5-4 0.11 us 0.12 us
Next CDB Byte Access (Byte 9 of 10) T23.10.9 4.5-4 0.13 us 0.14 us
Next CDB Byte Access (Byte 10 of 10) T23.10.10 4.5-4 0.12 us 0.16 us
Data In Byte Transfer (parameter) T24 4.5-12 0.06 us
Data Out Byte Transfer (parameter) T25 4.5-13 0.06 us
Next Data In Byte Access (parameter) T26 4.5-12 0.10 us 0.12 us
Next Data Out Byte Access (parameter) T27 4.5-13 0.11 us 0.14 us
Data In Byte Transfer (media) [2] T28 4.5-12 0.04 us 0.06 us
Data Out Byte Transfer (media) [2] T29 4.5-13 0.04 us 0.06 us
Next Data In Byte access (media [2] T30 4.5-12 0.10 us 0.14 us
Next Data Out Byte access (media [2] T31 4.5-13 0.10 us 0.14 us
MSG IN Byte Transfer T32 4.5-5,7 0.06 us
4.5-8,14,15
MSG OUT Byte Transfer T33 4.5-2 0.06 us
STATUS Byte Transfer T34 4.5-5,8 0.06 us
4.5-15
Synchronous Data Transfer Characteristics:
Request Signal Transfer Period [3] - - various 800 ns
Notes.
[1] See SCSI-2 Interface Manual P/N 77738479 (called Volume II), section 4.5
[2] Maximum SCSI asynchronous interface transfer rate is given in section 5.3.
[3] Synchronous Transfer Period is determined by negotiations between an Initiator and a Drive. The Drive
is capable of setting periods as given in section 11.5. See also sections 3.1.5.2 and 3.5.3.2 of the SCSI-
2 Interface Product Manual (P/N 77738479) for a description of synchronous data transfer operation.
General timing diagrams for SCSI interface operation are shown in the SCSI-2 Interface Product Manual
P/N 77738479, Section 4.5. The specific timing values that apply to this drive are listed in Table 11.7-1.
68
