Seagate STD2401LW-S - Figure 4. Internal Scorpion 40 Drive-Dimensions; Figure 5. Internal DDS Drive with Rails-Dimensions; Side View

8 Scorpion 40 DDS-4 Product Manual, Version A
41.3 mm
(1.63 in)
101.6 mm
(4.00 in)
101.6 mm
(4.00 in)
94.0 mm
(3.70 in)
3.8 mm (0.15 in)
13.0 mm (0.51 in)
2 places
5.0 mm (0.196 in)
2 places
90.0 mm
(3.54 in)
2 places
70.0 mm
(2.75 in)
6.0 mm
(0.24 in)
31.0 mm
(1.22 in)
146.0 mm
(5.75 in)
41.2 mm
(1.62 in)
60.0 mm
(2.36 in)
2 places
21.0 mm (0.83 in)
2 places
Side View
Bottom View
M3.0 x 4 deep min.
(10 places)
M3.0 x 4 deep min.
(4 places)
Note: Tolerance for all dimensions is 0.25mm (0.01 in)
Figure 4. Internal Scorpion 40 Drive—Dimensions
41.3 mm
(1.63 in)
31.5 mm (1.24 in)
146 mm
(5.75 in)
174.6 mm
(6.87 in)
79.4 mm
(3.13 in)
47.6 mm
(1.87 in)
21.8 mm (0.86 in)
9.9 mm (0.39 in)
16-M3
41.2 mm
(1.62 in)
139.7 mm (5.50 in)
149.1 mm (5.87 in)
Side View
Bottom View
Note: Tolerance for all dimensions is 0.25mm (0.01 in)
Figure 5. Internal DDS Drive with Rails—Dimensions
