Seagull Models SEA238 - Hinging the Rudder; Installing Control Horns; Aileron Control Horn Installation; Elevator Control Horn Installation

WWW.SEAGULLMODELS.COM
5
HINGING THE RUDDER.
Glue the top two rudder hinges in place
using the same techniques used to hinge
the ailerons.
e lower hinge will be glued when the
n/rudder assembly is attached to the fu-
selage.
INSTALL THE AILERONS
CONTROL HORN.
Epoxy.
Glue the elevator hinges in place using the
same techniques used to hing the ailerons.
Epoxy.
Epoxy.
Aileron control horn.
INSTALL ELEVATOR CONTROL HORN.
Fiberglass control horn
Fiberglass control horn
